Performance
6100–7210 MHz coverage, 64 CH
uucck 75D 7.2 GHz Video Receiver
$119.00
Skip to product information
uucck 75D 7.2 GHz Video Receiver
$119.00
No batteries
DDP · 27 EU countries
Ships from Guangzhou
USD · retail checkout
Small orders · PayPal & cards
The uucck 75D (VRX-75D class) is a 6.1–7.2 GHz analog receiver with 64 channels, CVBS output, RSSI, and a 7-segment UI — no OLED (see uucck 75DF for OLED).
Product overview
The uucck 75D (VRX-75D class) is a 6.1–7.2 GHz analog receiver with 64 channels, CVBS output, RSSI, and a 7-segment UI — no OLED (see uucck 75DF for OLED).
Key features
- Key capability6100–7210 MHz coverage, 64 CH
- Key capability−95 dBm sensitivity
- Key capability5–36 V wide input; RSSI output
- Verified PCB seriesFRXMT-V2.0 (7-seg, AT32F421)
Core advantages
Performance
−95 dBm sensitivity
Performance
5–36 V wide input; RSSI output
Performance
Verified PCB series: FRXMT-V2.0 (7-seg, AT32F421)
Target applications
- Ground stations and goggles receiving 6100–7210 (6.1–7.2 GHz) analog downlinks.
- Embedded DVR / monitor modules that need CVBS baseband video.
- Relay and companion receivers paired with uucck VTX on matching channel plans.
Technical specifications
RF
Video & interfaces
Power
Identification
Compatibility & pairing
Pair with uucck AL7210 or other 6–7.2 GHz VTX on the same 64-channel grid.
Setup & safety
Use jin1 主图 folder as-is (factory-verified 2026-10-17). Optional detail: sample PCB may show FRXMT-V2.0 marking.
Regulatory notice
Transmit only on frequencies and power levels approved in your country. Always connect a matched antenna before applying power. uucck modules are intended for licensed hobby and professional users who comply with local RF rules.
FAQ
Who manufactures uucck 75D?
uucck designs the product lineup and sells 75D at uucck.com. Technical data is verified against uucck engineering records (2026-10-17).
Analog or digital video?
This is analog FM CVBS — compatible with classic FPV goggles and monitors, not DJI HD digital links.
What PCB marking was verified on samples?
FRXMT-V2.0 20260307; MCU AT32F421; 7-seg (no OLED). Storefront SKU remains uucck 75D.
75D vs 75DF?
75D uses 7-seg display without OLED. 75DF adds OLED and auto-scan UX.
75D vs KP-R4861?
Different hardware: 75D is FRXMT 7.2 GHz class; KP-R4861 is FRX-V2.0 ultra-wide 4.8–7.2 GHz 176 CH module.
