Performance
4867–7210 MHz receive
uucck KP-R4861 4.9–7.2 GHz Video Receiver (176 CH)
$129.00
Skip to product information
uucck KP-R4861 4.9–7.2 GHz Video Receiver (176 CH)
$129.00
No batteries
DDP · 27 EU countries
Ships from Guangzhou
USD · retail checkout
Small orders · PayPal & cards
The uucck KP-R4861 is a wideband 4867–7210 MHz analog receiver with 176 channels, K1/K2 tuning, RSSI, and CVBS output — distinct from uucck 75DF OLED receiver.
Product overview
The uucck KP-R4861 is an ultra-wide 4.8–7.2 GHz VRX with 176 channels, SMA antenna, and CVBS output for ground stations that must cover multiple VTX bands.
Key features
- Key capability4867–7210 MHz receive
- Key capability176 channels (bands A–V, 8 channels each)
- Key capability5 V powered; 380±40 mA
- Key capabilityPCB marking FRX-V2.0 on verified sample
Core advantages
Performance
176 channels (bands A–V, 8 channels each)
Performance
5 V powered; 380±40 mA
Performance
PCB marking FRX-V2.0 on verified sample
Target applications
- Ground stations and goggles receiving 4867–7210 analog downlinks.
- Embedded DVR / monitor modules that need CVBS baseband video.
- Relay and companion receivers paired with uucck VTX on matching channel plans.
Technical specifications
RF
Video & control
Power
Compatibility & pairing
Works with uucck AL5805, AL5810, AL7210, ALV2.5W, and TX8000AC when channels overlap the stored table.
Setup & safety
Not the same board as uucck 75DF (OLED KP-RX4861 kit). Power from regulated 5 V bench supply in ground stations.
Regulatory notice
Transmit only on frequencies and power levels approved in your country. Always connect a matched antenna before applying power. uucck modules are intended for licensed hobby and professional users who comply with local RF rules.
FAQ
Who manufactures uucck KP-R4861?
uucck designs the product lineup and sells KP-R4861 at uucck.com. Technical data is verified against uucck engineering records (2026-10-17).
Analog or digital video?
This is analog FM CVBS — compatible with classic FPV goggles and monitors, not DJI HD digital links.
What PCB marking was verified on samples?
FRX-V2.0 20200307. Storefront SKU remains uucck KP-R4861.
Why FRX-V2.0 marking?
Factory PCB revision name; storefront SKU remains uucck KP-R4861.
Before you buy
- Carbon frames & video gear only — we do not sell batteries.
- DDP shipping to 27 European countries — shipping policy.
- Ships from Guangzhou, China (DHL partner flow).
- Checkout prices in USD.
Payment · small vs wholesale
- Small retail Pay on this site — total ≤ USD 499, ≤ 2 units/SKU, ≤ 9 units/order. PayPal or card (Visa, Mastercard, etc. via Airwallex). No crypto.
- Medium USD 500–1,999 or 3–9 units/line — we may review or send a draft invoice before shipping.
- Large / wholesale ≥ USD 2,000, ≥ 10 units/line, or ≥ 30 units — PI + bank transfer (Airwallex / WorldFirst). Not standard checkout. Contact us for a PI.
